Flat Bottom Silos

Flat Bottomed Silos are used for long term and high capacity storage needs with diameters varying from 4,58m to 32m and capacities up to 24.687 m³

Mastic

Mastic

Hot and cold resistant mastic is used in the joints of sidewall sheets to provide excellent sealling in all climates

Bolt

Bolt

At all junction points of sidewall sheets and stiffeners, DACROMET 500 coated 10.9 quality bolts are used in order to ensure the maximum durability. Thanks to the high density polyethylene conical gaskets found in bolts, sealing is kept at the highest level.

Bolt Type Durability Load (psi) Tensile Value (psi) Yield Strength (psi)
Grade 8 (10,9) 120.000 130.000 150.000
Grade 5 85.000 92.000 120.000

Sidewall Sheets

Sidewall Sheets

Mysilo, manufacturing more durable silos thanks to the narrowest corrugated sidewall sheet of 65 mm, has a huge advantage against its competitors with this feature.

Mysilo uses 600 gr/m² galvanized sidewall sheets at total on both surfaces which makes Mysilo silos long-lasting. With this, Mysilo is making a difference to their competitors who use less coating..

  • Mysilo,
    By further narrowing the wall sheet, which is considered to be the narrowest corrugated in the world (67.6 mm / 2.66 "), Mysilo is proud to be the only company to produce silos from the worlds narrowest corrugated wall (65mm / 2.56 ")

Galvanized

While competitors of Mysilo offer 600 gr. / m² galvanized coating as an option, Mysilo offers it as its Standard. Beside this, the silo’s lifetime is %120 longer** in comparison with the competitor’s standard quality galvanized coating rate 275 – 350 gr. / m²

Note:

** The amount of GALVANİSATİON on side wall sheet depends on the silo loading-unloading frequency and climate conditions such as snowing, sandstorm, wind speed and relative humidity. More friction on the wall sheets causes less lifetime for galvanization.

  • Format
    • Format Table
Filtrelettirdiğiniz, 'ün Alt ve Üst değerlerinin %20'si Alınmıştır.
  • Çap (mt)
  • Çap (ft)
  • Model
  • Ring
    Sayısı
  • Saçak Yüksekliği (m)
  • Tepe Yüksekliği (m)
  • Kapasite (m³)
  • Kapasite Buğday
    (ton)
  • Kapasite Mısır
    (ton)
  • Kapasite
    Arpa
    (ton)
Dia (mt) Dia (ft) Model Ring
Sayısı
Eave Height (m) Peak Height (m) Capacity (m³) Capacity Wheat
(TON)
CApacity Corn
(TON)
Capacity
Barley
(TON)
  • Çap 4,58 / 0504 Model
    4,58 15 0504 4 3,38 4,72 62 53 47 42
    4,58 15 0505 5 4,23 5,56 76 64 58 51
    4,58 15 0506 6 5,07 6,41 90 76 69 61
    4,58 15 0507 7 5,92 7,25 104 88 79 70
    4,58 15 0508 8 6,76 8,10 118 100 90 80
    4,58 15 0509 9 7,61 8,94 132 112 100 89
    4,58 15 0510 10 8,45 9,79 145 123 111 99
    4,58 15 0511 11 9,30 10,63 159 135 122 108
    4,58 15 0512 12 10,14 11,48 173 147 132 118
    4,58 15 0513 13 10,99 12,32 187 159 143 127
    4,58 15 0514 14 11,83 13,17 201 171 154 136
    4,58 15 0515 15 12,68 14,01 215 182 164 146
    4,58 15 0516 16 13,52 14,86 229 194 175 155
    4,58 15 0517 17 14,37 15,70 243 206 185 165
    4,58 15 0518 18 15,21 16,55 257 218 196 174
    4,58 15 0519 19 16,06 17,39 271 230 207 184
    4,58 15 0520 20 16,90 18,24 285 241 217 193
  • Çap 5,50 / 0606 Model
    5,50 18 0606 6 5,07 6,67 132 112 100 89
    5,50 18 0607 7 5,92 7,52 152 129 116 103
    5,50 18 0608 8 6,76 8,36 172 146 131 117
    5,50 18 0609 9 7,61 9,21 192 163 146 130
    5,50 18 0610 10 8,45 10,05 212 180 162 144
    5,50 18 0611 11 9,30 10,90 232 197 177 157
    5,50 18 0612 12 10,14 11,74 252 214 192 171
    5,50 18 0613 13 10,99 12,59 272 231 208 185
    5,50 18 0614 14 11,83 13,43 292 248 223 198
    5,50 18 0615 15 12,68 14,28 312 265 238 212
    5,50 18 0616 16 13,52 15,12 332 282 254 226
    5,50 18 0617 17 14,37 15,97 352 299 269 239
    5,50 18 0618 18 15,21 16,81 373 316 284 253
    5,50 18 0619 19 16,06 17,66 393 333 300 266
    5,50 18 0620 20 16,90 18,50 413 350 315 280
    5,50 18 0621 21 17,75 19,35 433 367 330 294
    5,50 18 0622 22 18,59 20,19 453 384 346 307
    5,50 18 0623 23 19,44 21,04 473 401 361 321
    5,50 18 0624 24 20,28 21,88 493 418 376 334
    5,50 18 0625 25 21,13 22,73 513 435 392 348
    5,50 18 0626 26 21,97 23,57 533 452 407 362
  • Çap 6,41 / 0706 Model
    6,41 21 0706 6 5,07 6,89 181 154 138 123
    6,41 21 0707 7 5,92 7,74 208 177 159 141
    6,41 21 0708 8 6,76 8,58 236 200 180 160
    6,41 21 0709 9 7,61 9,43 263 223 201 178
    6,41 21 0710 10 8,45 10,27 290 246 221 197
    6,41 21 0711 11 9,30 11,12 317 269 242 215
    6,41 21 0712 12 10,14 11,96 345 292 263 234
    6,41 21 0713 13 10,99 12,81 372 315 284 252
    6,41 21 0714 14 11,83 13,65 399 339 305 271
    6,41 21 0715 15 12,68 14,50 427 362 326 289
    6,41 21 0716 16 13,52 15,34 454 385 346 308
    6,41 21 0717 17 14,37 16,19 481 408 367 326
    6,41 21 0718 18 15,21 17,03 508 431 388 345
    6,41 21 0719 19 16,06 17,88 536 454 409 363
    6,41 21 0720 20 16,90 18,72 563 477 430 382
    6,41 21 0721 21 17,75 19,57 590 500 450 400
    6,41 21 0722 22 18,59 20,41 617 524 471 419
    6,41 21 0723 23 19,44 21,26 645 547 492 437
    6,41 21 0724 24 20,28 22,10 672 570 513 456
    6,41 21 0725 25 21,13 22,95 699 593 534 474
    6,41 21 0726 26 21,97 23,79 727 616 554 493
    6,41 21 0727 27 22,82 24,64 754 639 575 511
    6,41 21 0728 28 23,66 25,48 781 662 596 530
    6,41 21 0729 29 24,51 26,33 808 685 617 548
    6,41 21 0730 30 25,35 27,17 836 709 638 567
  • Çap 7,33 / 0806 Model
    7,33 27 0806 6 5,07 7,15 240 204 183 163
    7,33 27 0807 7 5,92 7,99 276 234 211 187
    7,33 27 0808 8 6,76 8,84 312 264 238 211
    7,33 27 0809 9 7,61 9,68 347 294 265 236
    7,33 27 0810 10 8,45 10,53 383 325 292 260
    7,33 27 0811 11 9,30 11,37 419 355 319 284
    7,33 27 0812 12 10,14 12,22 454 385 347 308
    7,33 27 0813 13 10,99 13,06 490 415 374 332
    7,33 27 0814 14 11,83 13,91 526 446 401 357
    7,33 27 0815 15 12,68 14,75 561 476 428 381
    7,33 27 0816 16 13,52 15,60 597 506 456 405
    7,33 27 0817 17 14,37 16,44 633 536 483 429
    7,33 27 0818 18 15,21 17,29 668 567 510 453
    7,33 27 0819 19 16,06 18,13 704 597 537 477
    7,33 27 0820 20 16,90 18,98 740 627 564 502
    7,33 27 0821 21 17,75 19,82 775 657 592 526
    7,33 27 0822 22 18,59 20,67 811 688 619 550
    7,33 27 0823 23 19,44 21,51 846 718 646 574
    7,33 27 0824 24 20,28 22,36 882 748 673 598
    7,33 27 0825 25 21,13 23,20 918 778 700 623
    7,33 27 0826 26 21,97 24,05 953 809 728 647
    7,33 27 0827 27 22,82 24,89 989 839 755 671
    7,33 27 0828 28 23,66 25,74 1,025 869 782 695
    7,33 27 0829 29 24,51 26,58 1,060 899 809 719
    7,33 27 0830 30 25,35 27,43 1,096 929 837 744
  • Çap 8,25 / 0906 Model
    8,25 27 0906 6 5,07 7,34 309 262 236 209
    8,25 27 0907 7 5,92 8,19 354 300 270 240
    8,25 27 0908 8 6,76 9,03 399 338 305 271
    8,25 27 0909 9 7,61 9,88 444 377 339 301
    8,25 27 0910 10 8,45 10,72 489 415 374 332
    8,25 27 0911 11 9,30 11,57 535 453 408 363
    8,25 27 0912 12 10,14 12,41 580 492 442 393
    8,25 27 0913 13 10,99 13,26 625 530 477 424
    8,25 27 0914 14 11,83 14,10 670 568 511 455
    8,25 27 0915 15 12,68 14,95 715 607 546 485
    8,25 27 0916 16 13,52 15,79 760 645 580 516
    8,25 27 0917 17 14,37 16,64 806 683 615 547
    8,25 27 0918 18 15,21 17,48 851 721 649 577
    8,25 27 0919 19 16,06 18,33 896 760 684 608
    8,25 27 0920 20 16,90 19,17 941 798 718 638
    8,25 27 0921 21 17,75 20,02 986 836 753 669
    8,25 27 0922 22 18,59 20,86 1,031 875 787 700
    8,25 27 0923 23 19,44 21,71 1,077 913 822 730
    8,25 27 0924 24 20,28 22,55 1,122 951 856 761
    8,25 27 0925 25 21,13 23,40 1,167 990 891 792
    8,25 27 0926 26 21,97 24,24 1,212 1,028 925 822
    8,25 27 0927 27 22,82 25,09 1,257 1,066 960 853
    8,25 27 0928 28 23,66 25,93 1,303 1,105 994 884
    8,25 27 0929 29 24,51 26,78 1,348 1,143 1,029 914
    8,25 27 0930 30 25,35 27,62 1,393 1,181 1,063 945
  • Çap 9,16 / 1008 Model
    9,16 30 1008 8 6,76 9,29 497 422 380 337
    9,16 30 1009 9 7,61 10,14 553 469 422 375
    9,16 30 1010 10 8,45 10,98 609 516 465 413
    9,16 30 1011 11 9,30 11,83 664 563 507 451
    9,16 30 1012 12 10,14 12,67 720 611 550 488
    9,16 30 1013 13 10,99 13,52 776 658 592 526
    9,16 30 1014 14 11,83 14,36 831 705 635 564
    9,16 30 1015 15 12,68 15,21 887 752 677 602
    9,16 30 1016 16 13,52 16,05 943 799 720 640
    9,16 30 1017 17 14,37 16,90 998 847 762 677
    9,16 30 1018 18 15,21 17,74 1,054 894 805 715
    9,16 30 1019 19 16,06 18,59 1,110 941 847 753
    9,16 30 1020 20 16,90 19,43 1,166 988 890 791
    9,16 30 1021 21 17,75 20,28 1,221 1,036 932 828
    9,16 30 1022 22 18,59 21,12 1,277 1,083 975 866
    9,16 30 1023 23 19,44 21,97 1,333 1,130 1,017 904
    9,16 30 1024 24 20,28 22,81 1,388 1,177 1,060 942
    9,16 30 1025 25 21,13 23,66 1,444 1,224 1,102 980
    9,16 30 1026 26 21,97 24,50 1,500 1,272 1,145 1,017
    9,16 30 1027 27 22,82 25,35 1,555 1,319 1,187 1,055
    9,16 30 1028 28 23,66 26,19 1,611 1,366 1,230 1,093
    9,16 30 1029 29 24,51 27,04 1,667 1,413 1,272 1,131
    9,16 30 1030 30 25,35 27,88 1,722 1,461 1,315 1,168
    9,16 30 1031 31 26,20 28,73 1,778 1,508 1,357 1,206
    9,16 30 1032 32 27,04 29,57 1,834 1,555 1,400 1,244
    9,16 30 1033 33 27,89 30,42 1,889 1,602 1,442 1,282
    9,16 30 1034 34 28,73 31,26 1,945 1,649 1,485 1,320
  • Çap 10,08 / 1108 Model
    10,08 33 1108 8 6,76 9,57 609 516 465 413
    10,08 33 1109 9 7,61 10,42 676 573 516 459
    10,08 33 1110 10 8,45 11,26 744 631 568 504
    10,08 33 1111 11 9,30 12,11 811 688 619 550
    10,08 33 1112 12 10,14 12,95 878 745 670 596
    10,08 33 1113 13 10,99 13,80 946 802 722 642
    10,08 33 1114 14 11,83 14,64 1,013 859 773 687
    10,08 33 1115 15 12,68 15,49 1,081 916 825 733
    10,08 33 1116 16 13,52 16,33 1,148 974 876 779
    10,08 33 1117 17 14,37 17,18 1,216 1,031 928 825
    10,08 33 1118 18 15,21 18,02 1,283 1,088 979 870
    10,08 33 1119 19 16,06 18,87 1,351 1,145 1,031 916
    10,08 33 1120 20 16,90 19,71 1,418 1,202 1,082 962
    10,08 33 1121 21 17,75 20,56 1,485 1,260 1,134 1,008
    10,08 33 1122 22 18,59 21,40 1,553 1,317 1,185 1,053
    10,08 33 1123 23 19,44 22,25 1,620 1,374 1,237 1,099
    10,08 33 1124 24 20,28 23,09 1,688 1,431 1,288 1,145
    10,08 33 1125 25 21,13 23,94 1,755 1,488 1,339 1,191
    10,08 33 1126 26 21,97 24,78 1,823 1,546 1,391 1,236
    10,08 33 1127 27 22,82 25,63 1,890 1,603 1,442 1,282
    10,08 33 1128 28 23,66 26,47 1,957 1,660 1,494 1,328
    10,08 33 1129 29 24,51 27,32 2,025 1,717 1,545 1,374
    10,08 33 1130 30 25,35 28,16 2,092 1,774 1,597 1,419
    10,08 33 1131 31 26,20 29,01 2,160 1,831 1,648 1,465
    10,08 33 1132 32 27,04 29,85 2,227 1,889 1,700 1,511
    10,08 33 1133 33 27,89 30,70 2,295 1,946 1,751 1,557
    10,08 33 1134 34 28,73 31,54 2,362 2,003 1,803 1,602
  • Çap 11,00 / 1208 Model
    11,00 36 1208 8 6,76 9,83 733 621 559 497
    11,00 36 1209 9 7,61 10,68 813 689 620 552
    11,00 36 1210 10 8,45 11,52 893 758 682 606
    11,00 36 1211 11 9,30 12,37 974 826 743 660
    11,00 36 1212 12 10,14 13,21 1,054 894 804 715
    11,00 36 1213 13 10,99 14,06 1,134 962 866 769
    11,00 36 1214 14 11,83 14,90 1,214 1,030 927 824
    11,00 36 1215 15 12,68 15,75 1,295 1,098 988 878
    11,00 36 1216 16 13,52 16,59 1,375 1,166 1,049 933
    11,00 36 1217 17 14,37 17,44 1,455 1,234 1,111 987
    11,00 36 1218 18 15,21 18,28 1,536 1,302 1,172 1,042
    11,00 36 1219 19 16,06 19,13 1,616 1,370 1,233 1,096
    11,00 36 1220 20 16,90 19,97 1,696 1,438 1,295 1,151
    11,00 36 1221 21 17,75 20,82 1,777 1,507 1,356 1,205
    11,00 36 1222 22 18,59 21,66 1,857 1,575 1,417 1,260
    11,00 36 1223 23 19,44 22,51 1,937 1,643 1,478 1,314
    11,00 36 1224 24 20,28 23,35 2,018 1,711 1,540 1,369
    11,00 36 1225 25 21,13 24,20 2,098 1,779 1,601 1,423
    11,00 36 1226 26 21,97 25,04 2,178 1,847 1,662 1,478
    11,00 36 1227 27 22,82 25,89 2,258 1,915 1,724 1,532
    11,00 36 1228 28 23,66 26,73 2,339 1,983 1,785 1,587
    11,00 36 1229 29 24,51 27,58 2,419 2,051 1,846 1,641
    11,00 36 1230 30 25,35 28,42 2,499 2,119 1,907 1,696
    11,00 36 1231 31 26,20 29,27 2,580 2,188 1,969 1,750
    11,00 36 1232 32 27,04 30,11 2,660 2,256 2,030 1,805
    11,00 36 1233 33 27,89 30,96 2,740 2,324 2,091 1,859
    11,00 36 1234 34 28,73 31,80 2,821 2,392 2,153 1,913
  • Çap 11,91 / 1308 Model
    11,91 39 1308 8 6,76 10,38 868 736 662 589
    11,91 39 1309 9 7,61 11,22 962 816 734 653
    11,91 39 1310 10 8,45 12,07 1,056 896 806 717
    11,91 39 1311 11 9,30 12,53 1,150 975 878 780
    11,91 39 1312 12 10,14 13,37 1,244 1,055 950 844
    11,91 39 1313 13 10,99 14,60 1,339 1,135 1,022 908
    11,91 39 1314 14 11,83 15,45 1,433 1,215 1,093 972
    11,91 39 1315 15 12,68 16,29 1,527 1,295 1,165 1,036
    11,91 39 1316 16 13,52 17,14 1,621 1,375 1,237 1,100
    11,91 39 1317 17 14,37 17,98 1,715 1,454 1,309 1,164
    11,91 39 1318 18 15,21 18,83 1,809 1,534 1,381 1,227
    11,91 39 1319 19 16,06 19,67 1,903 1,614 1,453 1,291
    11,91 39 1320 20 16,90 20,52 1,998 1,694 1,525 1,355
    11,91 39 1321 21 17,75 21,36 2,092 1,774 1,596 1,419
    11,91 39 1322 22 18,59 22,21 2,186 1,854 1,668 1,483
    11,91 39 1323 23 19,44 23,05 2,280 1,933 1,740 1,547
    11,91 39 1324 24 20,28 23,90 2,374 2,013 1,812 1,611
    11,91 39 1325 25 21,13 24,74 2,468 2,093 1,884 1,674
    11,91 39 1326 26 21,97 25,59 2,562 2,173 1,956 1,738
    11,91 39 1327 27 22,82 26,43 2,657 2,253 2,027 1,802
    11,91 39 1328 28 23,66 27,28 2,751 2,333 2,099 1,866
    11,91 39 1329 29 24,51 28,12 2,845 2,412 2,171 1,930
    11,91 39 1330 30 25,35 28,97 2,939 2,492 2,243 1,994
    11,91 39 1331 31 26,20 29,81 3,033 2,572 2,315 2,058
    11,91 39 1332 32 27,04 30,66 3,127 2,652 2,387 2,122
    11,91 39 1333 33 27,89 31,50 3,221 2,732 2,459 2,185
    11,91 39 1334 34 28,73 32,35 3,316 2,812 2,530 2,249
  • Çap 12,83 / 1408 Model
    12,83 42 1408 8 6,76 10,38 1,018 863 777 690
    12,83 42 1409 9 7,61 11,22 1,127 956 860 765
    12,83 42 1410 10 8,45 12,07 1,236 1,048 943 839
    12,83 42 1411 11 9,30 12,91 1,345 1,141 1,027 913
    12,83 42 1412 12 10,14 13,76 1,455 1,234 1,110 987
    12,83 42 1413 13 10,99 14,60 1,564 1,326 1,194 1,061
    12,83 42 1414 14 11,83 15,45 1,673 1,419 1,277 1,135
    12,83 42 1415 15 12,68 16,29 1,782 1,512 1,360 1,209
    12,83 42 1416 16 13,52 17,14 1,892 1,604 1,444 1,283
    12,83 42 1417 17 14,37 17,98 2,001 1,697 1,527 1,357
    12,83 42 1418 18 15,21 18,83 2,110 1,789 1,610 1,432
    12,83 42 1419 19 16,06 19,67 2,219 1,882 1,694 1,506
    12,83 42 1420 20 16,90 20,52 2,329 1,975 1,777 1,580
    12,83 42 1421 21 17,75 21,36 2,438 2,067 1,861 1,654
    12,83 42 1422 22 18,59 22,21 2,547 2,160 1,944 1,728
    12,83 42 1423 23 19,44 23,05 2,656 2,253 2,027 1,802
    12,83 42 1424 24 20,28 23,90 2,766 2,345 2,111 1,876
    12,83 42 1425 25 21,13 24,74 2,875 2,438 2,194 1,950
    12,83 42 1426 26 21,97 25,59 2,984 2,531 2,277 2,024
    12,83 42 1427 27 22,82 26,43 3,093 2,623 2,361 2,099
    12,83 42 1428 28 23,66 27,28 3,203 2,716 2,444 2,173
    12,83 42 1429 29 24,51 28,12 3,312 2,808 2,528 2,247
    12,83 42 1430 30 25,35 28,97 3,421 2,901 2,611 2,321
    12,83 42 1431 31 26,20 29,81 3,530 2,994 2,694 2,395
    12,83 42 1432 32 27,04 30,66 3,640 3,086 2,778 2,469
    12,83 42 1433 33 27,89 31,50 3,749 3,179 2,861 2,543
    12,83 42 1434 34 28,73 32,35 3,858 3,272 2,944 2,617
  • Çap 13,74 / 1508 Model
    13,74 45 1508 8 6,76 10,56 1,179 1,000 900 800
    13,74 45 1509 9 7,61 11,41 1,304 1,106 995 885
    13,74 45 1510 10 8,45 12,25 1,430 1,212 1,091 970
    13,74 45 1511 11 9,30 13,10 1,555 1,319 1,187 1,055
    13,74 45 1512 12 10,14 13,94 1,680 1,425 1,282 1,140
    13,74 45 1513 13 10,99 14,79 1,805 1,531 1,378 1,225
    13,74 45 1514 14 11,83 15,63 1,931 1,637 1,474 1,310
    13,74 45 1515 15 12,68 16,48 2,056 1,744 1,569 1,395
    13,74 45 1516 16 13,52 17,32 2,181 1,850 1,665 1,480
    13,74 45 1517 17 14,37 18,17 2,307 1,956 1,760 1,565
    13,74 45 1518 18 15,21 19,01 2,432 2,062 1,856 1,650
    13,74 45 1519 19 16,06 19,86 2,557 2,169 1,952 1,735
    13,74 45 1520 20 16,90 20,70 2,683 2,275 2,047 1,820
    13,74 45 1521 21 17,75 21,55 2,808 2,381 2,143 1,905
    13,74 45 1522 22 18,59 22,39 2,933 2,487 2,239 1,990
    13,74 45 1523 23 19,44 23,24 3,058 2,594 2,334 2,075
    13,74 45 1524 24 20,28 24,08 3,184 2,700 2,430 2,160
    13,74 45 1525 25 21,13 24,93 3,309 2,806 2,525 2,245
    13,74 45 1526 26 21,97 25,77 3,434 2,912 2,621 2,330
    13,74 45 1527 27 22,82 26,62 3,560 3,018 2,717 2,415
    13,74 45 1528 28 23,66 27,46 3,685 3,125 2,812 2,500
    13,74 45 1529 29 24,51 28,31 3,810 3,231 2,908 2,585
    13,74 45 1530 30 25,35 29,15 3,935 3,337 3,004 2,670
    13,74 45 1531 31 26,20 30,00 4,061 3,443 3,099 2,755
    13,74 45 1532 32 27,04 30,84 4,186 3,550 3,195 2,840
    13,74 45 1533 33 27,89 31,69 4,311 3,656 3,290 2,925
    13,74 45 1534 34 28,73 32,53 4,437 3,762 3,386 3,010
  • Çap 14,66 / 1608 Model
    14,66 48 1608 8 6,76 10,90 1,356 1,150 1,035 920
    14,66 48 1609 9 7,61 11,75 1,499 1,271 1,144 1,017
    14,66 48 1610 10 8,45 12,59 1,641 1,392 1,253 1,113
    14,66 48 1611 11 9,30 13,44 1,784 1,513 1,362 1,210
    14,66 48 1612 12 10,14 14,28 1,927 1,634 1,470 1,307
    14,66 48 1613 13 10,99 15,13 2,069 1,755 1,579 1,404
    14,66 48 1614 14 11,83 15,97 2,212 1,876 1,688 1,501
    14,66 48 1615 15 12,68 16,82 2,355 1,997 1,797 1,597
    14,66 48 1616 16 13,52 17,66 2,497 2,118 1,906 1,694
    14,66 48 1617 17 14,37 18,51 2,640 2,239 2,015 1,791
    14,66 48 1618 18 15,21 19,35 2,782 2,359 2,124 1,888
    14,66 48 1619 19 16,06 20,20 2,925 2,480 2,232 1,984
    14,66 48 1620 20 16,90 21,04 3,068 2,601 2,341 2,081
    14,66 48 1621 21 17,75 21,89 3,210 2,722 2,450 2,178
    14,66 48 1622 22 18,59 22,73 3,353 2,843 2,559 2,275
    14,66 48 1623 23 19,44 23,58 3,496 2,964 2,668 2,371
    14,66 48 1624 24 20,28 24,42 3,638 3,085 2,777 2,468
    14,66 48 1625 25 21,13 25,27 3,781 3,206 2,886 2,565
    14,66 48 1626 26 21,97 26,11 3,923 3,327 2,994 2,662
    14,66 48 1627 27 22,82 26,96 4,066 3,448 3,103 2,758
    14,66 48 1628 28 23,66 27,80 4,209 3,569 3,212 2,855
    14,66 48 1629 29 24,51 28,65 4,351 3,690 3,321 2,952
    14,66 48 1630 30 25,35 29,49 4,494 3,811 3,430 3,049
    14,66 48 1631 31 26,20 30,34 4,637 3,932 3,539 3,145
    14,66 48 1632 32 27,04 31,18 4,779 4,053 3,648 3,242
    14,66 48 1633 33 27,89 32,03 4,922 4,174 3,756 3,339
    14,66 48 1634 34 28,73 32,87 5,065 4,295 3,865 3,436
  • Çap 15,58 / 1708 Model
    15,58 51 1708 8 6,76 10,96 1,547 1,312 1,181 1,050
    15,58 51 1709 9 7,61 11,81 1,708 1,449 1,304 1,159
    15,58 51 1710 10 8,45 12,65 1,869 1,585 1,427 1,268
    15,58 51 1711 11 9,30 13,50 2,030 1,722 1,550 1,377
    15,58 51 1712 12 10,14 14,34 2,192 1,858 1,673 1,487
    15,58 51 1713 13 10,99 15,19 2,353 1,995 1,796 1,596
    15,58 51 1714 14 11,83 16,03 2,514 2,132 1,919 1,705
    15,58 51 1715 15 12,68 16,88 2,675 2,268 2,041 1,815
    15,58 51 1716 16 13,52 17,72 2,836 2,405 2,164 1,924
    15,58 51 1717 17 14,37 18,57 2,997 2,542 2,287 2,033
    15,58 51 1718 18 15,21 19,41 3,158 2,678 2,410 2,142
    15,58 51 1719 19 16,06 20,26 3,319 2,815 2,533 2,252
    15,58 51 1720 20 16,90 21,10 3,480 2,951 2,656 2,361
    15,58 51 1721 21 17,75 21,95 3,641 3,088 2,779 2,470
    15,58 51 1722 22 18,59 22,79 3,803 3,225 2,902 2,580
    15,58 51 1723 23 19,44 23,64 3,964 3,361 3,025 2,689
    15,58 51 1724 24 20,28 24,48 4,125 3,498 3,148 2,798
    15,58 51 1725 25 21,13 25,33 4,286 3,634 3,271 2,908
    15,58 51 1726 26 21,97 26,17 4,447 3,771 3,394 3,017
    15,58 51 1727 27 22,82 27,02 4,608 3,908 3,517 3,126
    15,58 51 1728 28 23,66 27,86 4,769 4,044 3,640 3,235
    15,58 51 1729 29 24,51 28,71 4,930 4,181 3,763 3,345
    15,58 51 1730 30 25,35 29,55 5,091 4,317 3,886 3,454
    15,58 51 1731 31 26,20 30,40 5,252 4,454 4,009 3,563
    15,58 51 1732 32 27,04 31,24 5,413 4,591 4,132 3,673
    15,58 51 1733 33 27,89 32,09 5,575 4,727 4,255 3,782
    15,58 51 1734 34 28,73 32,93 5,736 4,864 4,377 3,891
  • Çap 16,49 / 1808 Model
    16,49 54 1808 8 6,76 11,19 1,753 1,486 1,338 1,189
    16,49 54 1809 9 7,61 12,04 1,933 1,640 1,476 1,312
    16,49 54 1810 10 8,45 12,88 2,114 1,793 1,614 1,434
    16,49 54 1811 11 9,30 13,73 2,295 1,946 1,751 1,557
    16,49 54 1812 12 10,14 14,57 2,476 2,099 1,889 1,679
    16,49 54 1813 13 10,99 15,42 2,656 2,252 2,027 1,802
    16,49 54 1814 14 11,83 16,26 2,837 2,406 2,165 1,925
    16,49 54 1815 15 12,68 17,11 3,018 2,559 2,303 2,047
    16,49 54 1816 16 13,52 17,95 3,198 2,712 2,441 2,170
    16,49 54 1817 17 14,37 18,80 3,379 2,865 2,579 2,292
    16,49 54 1818 18 15,21 19,64 3,560 3,019 2,717 2,415
    16,49 54 1819 19 16,06 20,49 3,740 3,172 2,855 2,537
    16,49 54 1820 20 16,90 21,33 3,921 3,325 2,992 2,660
    16,49 54 1821 21 17,75 22,18 4,102 3,478 3,130 2,783
    16,49 54 1822 22 18,59 23,02 4,282 3,631 3,268 2,905
    16,49 54 1823 23 19,44 23,87 4,463 3,785 3,406 3,028
    16,49 54 1824 24 20,28 24,71 4,644 3,938 3,544 3,150
    16,49 54 1825 25 21,13 25,56 4,824 4,091 3,682 3,273
    16,49 54 1826 26 21,97 26,40 5,005 4,244 3,820 3,395
    16,49 54 1827 27 22,82 27,25 5,186 4,398 3,958 3,518
    16,49 54 1828 28 23,66 28,09 5,366 4,551 4,096 3,641
    16,49 54 1829 29 24,51 28,94 5,547 4,704 4,234 3,763
    16,49 54 1830 30 25,35 29,78 5,728 4,857 4,371 3,886
    16,49 54 1831 31 26,20 30,63 5,908 5,010 4,509 4,008
    16,49 54 1832 32 27,04 31,47 6,089 5,164 4,647 4,131
    16,49 54 1833 33 27,89 32,32 6,270 5,317 4,785 4,253
    16,49 54 1834 34 28,73 33,16 6,451 5,470 4,923 4,376
    16,49 54 1835 35 29,58 34,01 6,631 5,623 5,061 4,499
  • Çap 18,33 / 2008 Model
    18,33 60 2008 8 6,76 11,74 2,206 1,871 1,684 1,496
    18,33 60 2009 9 7,61 12,58 2,429 2,060 1,854 1,648
    18,33 60 2010 10 8,45 13,43 2,652 2,249 2,024 1,799
    18,33 60 2011 11 9,30 14,27 2,875 2,438 2,194 1,950
    18,33 60 2012 12 10,14 15,12 3,098 2,627 2,364 2,102
    18,33 60 2013 13 10,99 15,96 3,321 2,816 2,534 2,253
    18,33 60 2014 14 11,83 16,81 3,544 3,005 2,705 2,404
    18,33 60 2015 15 12,68 17,65 3,767 3,194 2,875 2,555
    18,33 60 2016 16 13,52 18,50 3,990 3,383 3,045 2,707
    18,33 60 2017 17 14,37 19,34 4,213 3,572 3,215 2,858
    18,33 60 2018 18 15,21 20,19 4,436 3,762 3,385 3,009
    18,33 60 2019 19 16,06 21,03 4,659 3,951 3,556 3,160
    18,33 60 2020 20 16,90 21,88 4,882 4,140 3,726 3,312
    18,33 60 2021 21 17,75 22,72 5,105 4,329 3,896 3,463
    18,33 60 2022 22 18,59 23,57 5,328 4,518 4,066 3,614
    18,33 60 2023 23 19,44 24,41 5,551 4,707 4,236 3,766
    18,33 60 2024 24 20,28 25,26 5,774 4,896 4,406 3,917
    18,33 60 2025 25 21,13 26,10 5,997 5,085 4,577 4,068
    18,33 60 2026 26 21,97 26,95 6,220 5,274 4,747 4,219
    18,33 60 2027 27 22,82 27,79 6,443 5,463 4,917 4,371
    18,33 60 2028 28 23,66 28,64 6,666 5,652 5,087 4,522
    18,33 60 2029 29 24,51 29,48 6,889 5,841 5,257 4,673
    18,33 60 2030 30 25,35 30,33 7,112 6,031 5,428 4,824
    18,33 60 2031 31 26,20 31,17 7,335 6,220 5,598 4,976
    18,33 60 2032 32 27,04 32,02 7,557 6,409 5,768 5,127
    18,33 60 2033 33 27,89 32,86 7,780 6,598 5,938 5,278
    18,33 60 2034 34 28,73 33,71 8,003 6,787 6,108 5,430
    18,33 60 2035 35 29,58 34,55 8,226 6,976 6,278 5,581
  • Çap 20,16 / 2208 Model
    20,16 66 2208 8 6,76 12,34 2,720 2,307 2,076 1,845
    20,16 66 2209 9 7,61 13,19 2,990 2,535 2,282 2,028
    20,16 66 2210 10 8,45 14,03 3,260 2,764 2,488 2,211
    20,16 66 2211 11 9,30 14,88 3,529 2,993 2,694 2,394
    20,16 66 2212 12 10,14 15,72 3,799 3,222 2,899 2,577
    20,16 66 2213 13 10,99 16,57 4,069 3,450 3,105 2,760
    20,16 66 2214 14 11,83 17,41 4,339 3,679 3,311 2,943
    20,16 66 2215 15 12,68 18,26 4,608 3,908 3,517 3,126
    20,16 66 2216 16 13,52 19,10 4,878 4,137 3,723 3,309
    20,16 66 2217 17 14,37 19,95 5,148 4,365 3,929 3,492
    20,16 66 2218 18 15,21 20,79 5,417 4,594 4,135 3,675
    20,16 66 2219 19 16,06 21,64 5,687 4,823 4,340 3,858
    20,16 66 2220 20 16,90 22,48 5,957 5,051 4,546 4,041
    20,16 66 2221 21 17,75 23,33 6,227 5,280 4,752 4,224
    20,16 66 2222 22 18,59 24,17 6,496 5,509 4,958 4,407
    20,16 66 2223 23 19,44 25,02 6,766 5,738 5,164 4,590
    20,16 66 2224 24 20,28 25,86 7,036 5,966 5,370 4,773
    20,16 66 2225 25 21,13 26,71 7,306 6,195 5,576 4,956
    20,16 66 2226 26 21,97 27,55 7,575 6,424 5,781 5,139
    20,16 66 2227 27 22,82 28,40 7,845 6,653 5,987 5,322
    20,16 66 2228 28 23,66 29,24 8,115 6,881 6,193 5,505
    20,16 66 2229 29 24,51 30,09 8,384 7,110 6,399 5,688
    20,16 66 2230 30 25,35 30,93 8,654 7,339 6,605 5,871
    20,16 66 2231 31 26,20 31,78 8,924 7,567 6,811 6,054
    20,16 66 2232 32 27,04 32,62 9,194 7,796 7,017 6,237
    20,16 66 2233 33 27,89 33,47 9,463 8,025 7,222 6,420
    20,16 66 2234 34 28,73 34,31 9,733 8,254 7,428 6,603
    20,16 66 2235 35 29,58 35,16 10,003 8,482 7,634 6,786
  • Çap 21,99 / 2408 Model
    21,99 72 2408 8 6,76 12,87 3,298 2,797 2,517 2,237
    21,99 72 2409 9 7,61 13,71 3,619 3,069 2,762 2,455
    21,99 72 2410 10 8,45 14,56 3,940 3,341 3,007 2,673
    21,99 72 2411 11 9,30 15,40 4,261 3,613 3,252 2,890
    21,99 72 2412 12 10,14 16,25 4,582 3,885 3,497 3,108
    21,99 72 2413 13 10,99 17,09 4,903 4,157 3,742 3,326
    21,99 72 2414 14 11,83 17,94 5,223 4,429 3,987 3,544
    21,99 72 2415 15 12,68 18,78 5,544 4,702 4,231 3,761
    21,99 72 2416 16 13,52 19,63 5,865 4,974 4,476 3,979
    21,99 72 2417 17 14,37 20,47 6,186 5,246 4,721 4,197
    21,99 72 2418 18 15,21 21,32 6,507 5,518 4,966 4,414
    21,99 72 2419 19 16,06 22,16 6,828 5,790 5,211 4,632
    21,99 72 2420 20 16,90 23,01 7,149 6,062 5,456 4,850
    21,99 72 2421 21 17,75 23,85 7,470 6,334 5,701 5,068
    21,99 72 2422 22 18,59 24,70 7,791 6,607 5,946 5,285
    21,99 72 2423 23 19,44 25,54 8,112 6,879 6,191 5,503
    21,99 72 2424 24 20,28 26,39 8,433 7,151 6,436 5,721
    21,99 72 2425 25 21,13 27,23 8,754 7,423 6,681 5,938
    21,99 72 2426 26 21,97 28,08 9,075 7,695 6,926 6,156
    21,99 72 2427 27 22,82 28,92 9,395 7,967 7,171 6,374
    21,99 72 2428 28 23,66 29,77 9,716 8,239 7,416 6,592
    21,99 72 2429 29 24,51 30,61 10,037 8,512 7,660 6,809
    21,99 72 2430 30 25,35 31,46 10,358 8,784 7,905 7,027
    21,99 72 2431 31 26,20 32,30 10,679 9,056 8,150 7,245
    21,99 72 2432 32 27,04 33,15 11,000 9,328 8,395 7,462
    21,99 72 2433 33 27,89 33,99 11,321 9,600 8,640 7,680
    21,99 72 2434 34 28,73 34,84 11,642 9,872 8,885 7,898
    21,99 72 2435 35 29,58 35,68 11,963 10,144 9,130 8,116
  • Çap 22,91 / 2508 Model
    22,91 75 2508 8 6,76 13,13 3,613 3,064 2,758 2,451
    22,91 75 2509 9 7,61 13,97 3,962 3,359 3,024 2,688
    22,91 75 2510 10 8,45 14,82 4,310 3,655 3,289 2,924
    22,91 75 2511 11 9,30 15,66 4,658 3,950 3,555 3,160
    22,91 75 2512 12 10,14 16,51 5,007 4,246 3,821 3,397
    22,91 75 2513 13 10,99 17,35 5,355 4,541 4,087 3,633
    22,91 75 2514 14 11,83 18,20 5,703 4,836 4,353 3,869
    22,91 75 2515 15 12,68 19,04 6,052 5,132 4,619 4,105
    22,91 75 2516 16 13,52 19,89 6,400 5,427 4,884 4,342
    22,91 75 2517 17 14,37 20,73 6,748 5,723 5,150 4,578
    22,91 75 2518 18 15,21 21,58 7,097 6,018 5,416 4,814
    22,91 75 2519 19 16,06 22,42 7,445 6,313 5,682 5,051
    22,91 75 2520 20 16,90 23,27 7,793 6,609 5,948 5,287
    22,91 75 2521 21 17,75 24,11 8,142 6,904 6,214 5,523
    22,91 75 2522 22 18,59 24,96 8,490 7,200 6,480 5,760
    22,91 75 2523 23 19,44 25,80 8,838 7,495 6,745 5,996
    22,91 75 2524 24 20,28 26,65 9,187 7,790 7,011 6,232
    22,91 75 2525 25 21,13 27,49 9,535 8,086 7,277 6,469
    22,91 75 2526 26 21,97 28,34 9,883 8,381 7,543 6,705
    22,91 75 2527 27 22,82 29,18 10,232 8,676 7,809 6,941
    22,91 75 2528 28 23,66 30,03 10,580 8,972 8,075 7,177
    22,91 75 2529 29 24,51 30,87 10,928 9,267 8,341 7,414
    22,91 75 2530 30 25,35 31,72 11,277 9,563 8,606 7,650
    22,91 75 2531 31 26,20 32,56 11,625 9,858 8,872 7,886
    22,91 75 2532 32 27,04 33,41 11,973 10,153 9,138 8,123
    22,91 75 2533 33 27,89 34,25 12,322 10,449 9,404 8,359
    22,91 75 2534 34 28,73 35,10 12,670 10,744 9,670 8,595
    22,91 75 2535 35 29,58 35,94 13,018 11,040 9,936 8,832
  • Çap 23,84 / 2608 Model
    23,84 78 2608 8 6,76 13,41 3,949 3,349 3,014 2,679
    23,84 78 2609 9 7,61 14,26 4,327 3,669 3,302 2,935
    23,84 78 2610 10 8,45 15,10 4,704 3,989 3,590 3,191
    23,84 78 2611 11 9,30 15,95 5,081 4,309 3,878 3,447
    23,84 78 2612 12 10,14 16,79 5,458 4,629 4,166 3,703
    23,84 78 2613 13 10,99 17,64 5,835 4,948 4,454 3,959
    23,84 78 2614 14 11,83 18,48 6,213 5,268 4,741 4,215
    23,84 78 2615 15 12,68 19,33 6,590 5,588 5,029 4,470
    23,84 78 2616 16 13,52 20,17 6,967 5,908 5,317 4,726
    23,84 78 2617 17 14,37 21,02 7,344 6,228 5,605 4,982
    23,84 78 2618 18 15,21 21,86 7,721 6,548 5,893 5,238
    23,84 78 2619 19 16,06 22,71 8,098 6,868 6,181 5,494
    23,84 78 2620 20 16,90 23,55 8,476 7,187 6,469 5,750
    23,84 78 2621 21 17,75 24,40 8,853 7,507 6,757 6,006
    23,84 78 2622 22 18,59 25,24 9,230 7,827 7,044 6,262
    23,84 78 2623 23 19,44 26,09 9,607 8,147 7,332 6,518
    23,84 78 2624 24 20,28 26,93 9,984 8,467 7,620 6,773
    23,84 78 2625 25 21,13 27,78 10,362 8,787 7,908 7,029
    23,84 78 2626 26 21,97 28,62 10,739 9,107 8,196 7,285
    23,84 78 2627 27 22,82 29,47 11,116 9,426 8,484 7,541
    23,84 78 2628 28 23,66 30,31 11,493 9,746 8,772 7,797
    23,84 78 2629 29 24,51 31,16 11,870 10,066 9,059 8,053
    23,84 78 2630 30 25,35 32,00 12,248 10,386 9,347 8,309
    23,84 78 2631 31 26,20 32,85 12,625 10,706 9,635 8,565
    23,84 78 2632 32 27,04 33,69 13,002 11,026 9,923 8,821
    23,84 78 2633 33 27,89 34,54 13,379 11,345 10,211 9,076
    23,84 78 2634 34 28,73 35,38 13,756 11,665 10,499 9,332
    23,84 78 2635 35 29,58 36,23 14,134 11,985 10,787 9,588
  • Çap 25,66 / 2808 Model
    25,66 84 2808 8 6,76 13,94 4,659 3,951 3,556 3,161
    25,66 84 2809 9 7,61 14,79 5,096 4,321 3,889 3,457
    25,66 84 2810 10 8,45 15,63 5,533 4,692 4,223 3,753
    25,66 84 2811 11 9,30 16,48 5,970 5,062 4,556 4,050
    25,66 84 2812 12 10,14 17,32 6,407 5,433 4,890 4,346
    25,66 84 2813 13 10,99 18,17 6,844 5,804 5,223 4,643
    25,66 84 2814 14 11,83 19,01 7,281 6,174 5,557 4,939
    25,66 84 2815 15 12,68 19,86 7,718 6,545 5,890 5,236
    25,66 84 2816 16 13,52 20,70 8,155 6,915 6,224 5,532
    25,66 84 2817 17 14,37 21,55 8,592 7,286 6,557 5,829
    25,66 84 2818 18 15,21 22,39 9,029 7,656 6,891 6,125
    25,66 84 2819 19 16,06 23,24 9,466 8,027 7,224 6,421
    25,66 84 2820 20 16,90 24,08 9,903 8,397 7,558 6,718
    25,66 84 2821 21 17,75 24,93 10,340 8,768 7,891 7,014
    25,66 84 2822 22 18,59 25,77 10,777 9,139 8,225 7,311
    25,66 84 2823 23 19,44 26,62 11,214 9,509 8,558 7,607
    25,66 84 2824 24 20,28 27,46 11,651 9,880 8,892 7,904
    25,66 84 2825 25 21,13 28,31 12,087 10,250 9,225 8,200
    25,66 84 2826 26 21,97 29,15 12,524 10,621 9,559 8,497
    25,66 84 2827 27 22,82 30,00 12,961 10,991 9,892 8,793
    25,66 84 2828 28 23,66 30,84 13,398 11,362 10,226 9,089
    25,66 84 2829 29 24,51 31,69 13,835 11,732 10,559 9,386
    25,66 84 2830 30 25,35 32,53 14,272 12,103 10,893 9,682
    25,66 84 2831 31 26,20 33,38 14,709 12,474 11,226 9,979
    25,66 84 2832 32 27,04 34,22 15,146 12,844 11,560 10,275
    25,66 84 2833 33 27,89 35,07 15,583 13,215 11,893 10,572
    25,66 84 2834 34 28,73 35,91 16,020 13,585 12,227 10,868
  • Çap 27,49 / 3008 Model
    27,49 90 3008 8 6,76 14,17 5,448 4,620 4,158 3,696
    27,49 90 3009 9 7,61 15,02 5,950 5,045 4,541 4,036
    27,49 90 3010 10 8,45 15,86 6,452 5,471 4,924 4,377
    27,49 90 3011 11 9,30 16,71 6,953 5,897 5,307 4,717
    27,49 90 3012 12 10,14 17,55 7,455 6,322 5,690 5,058
    27,49 90 3013 13 10,99 18,40 7,957 6,748 6,073 5,398
    27,49 90 3014 14 11,83 19,24 8,459 7,173 6,456 5,739
    27,49 90 3015 15 12,68 20,09 8,961 7,599 6,839 6,079
    27,49 90 3016 16 13,52 20,93 9,463 8,025 7,222 6,420
    27,49 90 3017 17 14,37 21,78 9,965 8,450 7,605 6,760
    27,49 90 3018 18 15,21 22,62 10,467 8,876 7,988 7,101
    27,49 90 3019 19 16,06 23,47 10,969 9,301 8,371 7,441
    27,49 90 3020 20 16,90 24,31 11,471 9,727 8,754 7,782
    27,49 90 3021 21 17,75 25,16 11,972 10,153 9,137 8,122
    27,49 90 3022 22 18,59 26,00 12,474 10,578 9,520 8,463
    27,49 90 3023 23 19,44 26,85 12,976 11,004 9,903 8,803
    27,49 90 3024 24 20,28 27,69 13,478 11,429 10,286 9,144
    27,49 90 3025 25 21,13 28,54 13,980 11,855 10,670 9,484
    27,49 90 3026 26 21,97 29,38 14,482 12,281 11,053 9,824
    27,49 90 3027 27 22,82 30,23 14,984 12,706 11,436 10,165
    27,49 90 3028 28 23,66 31,07 15,486 13,132 11,819 10,505
    27,49 90 3029 29 24,51 31,92 15,988 13,557 12,202 10,846
    27,49 90 3030 30 25,35 32,76 16,489 13,983 12,585 11,186
    27,49 90 3031 31 26,20 33,61 16,991 14,409 12,968 11,527
    27,49 90 3032 32 27,04 34,45 17,493 14,834 13,351 11,867
    27,49 90 3033 33 27,89 35,30 17,995 15,260 13,734 12,208
    27,49 90 3034 34 28,73 36,14 18,497 15,685 14,117 12,548
  • Çap 32,07 / 3508 Model
    32,07 105 3508 8 6,76 15,89 7,697 6,527 5,874 5,222
    32,07 105 3509 9 7,61 16,73 8,377 7,104 6,393 5,683
    32,07 105 3510 10 8,45 17,58 9,056 7,680 6,912 6,144
    32,07 105 3511 11 9,30 18,42 9,736 8,256 7,430 6,605
    32,07 105 3512 12 10,14 19,27 10,416 8,832 7,949 7,066
    32,07 105 3513 13 10,99 20,11 11,095 9,409 8,468 7,527
    32,07 105 3514 14 11,83 20,96 11,775 9,985 8,986 7,988
    32,07 105 3515 15 12,68 21,80 12,454 10,561 9,505 8,449
    32,07 105 3516 16 13,52 22,65 13,134 11,138 10,024 8,910
    32,07 105 3517 17 14,37 23,49 13,813 11,714 10,542 9,371
    32,07 105 3518 18 15,21 24,34 14,493 12,290 11,061 9,832
    32,07 105 3519 19 16,06 25,18 15,173 12,866 11,580 10,293
    32,07 105 3520 20 16,90 26,03 15,852 13,443 12,098 10,754
    32,07 105 3521 21 17,75 26,87 16,532 14,019 12,617 11,215
    32,07 105 3522 22 18,59 27,72 17,211 14,595 13,136 11,676
    32,07 105 3523 23 19,44 28,56 17,891 15,172 13,654 12,137
    32,07 105 3524 24 20,28 29,41 18,571 15,748 14,173 12,598
    32,07 105 3525 25 21,13 30,25 19,250 16,324 14,692 13,059
    32,07 105 3526 26 21,97 31,10 19,930 16,900 15,210 13,520
    32,07 105 3527 27 22,82 31,94 20,609 17,477 15,729 13,981
    32,07 105 3528 28 23,66 32,79 21,289 18,053 16,248 14,442
    32,07 105 3529 29 24,51 33,63 21,969 18,629 16,766 14,903
    32,07 105 3530 30 25,35 34,48 22,648 19,206 17,285 15,365
    32,07 105 3531 31 26,20 35,32 23,328 19,782 17,804 15,826
    32,07 105 3532 32 27,04 36,17 24,007 20,358 18,322 16,287
    32,07 105 3533 33 27,89 37,01 24,687 20,935 18,841 16,748
  • * %6 grain compaction rate and 28° grain repose angle has been taken into consideration on capacity calculations.
  • ** All silos are designed fort he storage of grain and other free-flowing materials weighing up to 833 kg/m³.
  • *** Approximate grain densities: Wheat= 800 kg/m³, Corn= 721 kg/m³, Barley= 640 kg/m³
  • **** Specifications and design are subject to change without notice.
  • ***** The values in the tables are approximate values.

EL MAYOR PRODUCTOR DE EUROPA DE SILO Mysilo

Mysilo equipo de expertos que funciona mejor para usted,
ofrecer soluciones llave en mano profesional.
Servicio al Cliente

+90 444
